FCX10 Chevy K5 Blazer Black 1\/10 Scale 4WD Crawler - RTR from FMS - FMS11001RSBK
Version Info: This model is assembled, painted, and ready to run but require a 2S or 3S LiPo battery pack and suitable charger along with 4 AA batteries for the transmitter (sold separately).
Whether navigating rugged mountain paths or making a statement on city streets, the Chevrolet K5 Blazer embodies the spirit of freedom, adventure, and individuality. With its iconic upright front grille and bold square body lines, it has become an emblem of American automotive culture. This 1\/10 scale model of the Chevrolet K5 Blazer, officially licensed by General Motors and produced by FMS, faithfully captures the essence of the original vehicle.
Built on the FCX10 crawler platform, it boasts a host of features including DIG, switchable 2WD\/4WD, lockable front and rear differentials, a two-speed transmission, portal axles, and more. With the FCX K5's innovative 2WD\/4WD transmitter switch function, users can seamlessly transition between power output modes such as DIG\/4WD\/FWD or RWD\/4WD\/FWD, offering versatility for various terrain conditions.
Here's a breakdown of the power output modes:


FWD (Front-Wheel Drive): Utilizes the front wheels as the driving wheels, enhancing agility and maneuverability during turns.

RWD (Rear-Wheel Drive): Employs the rear wheels as the driving wheels, ideal for high-speed maneuvers and stability.

4WD (Four-Wheel Drive): Engages all four wheels to deliver maximum power output, enabling exceptional crawling capabilities on challenging terrain.

Combine the versatile, go-anywhere fun of the FMS FCX10 Chevy K5 Blazer 1\/10 Scale 4WD Crawler RTR with Motion RC’s industry-leading customer service and product support for an unbeatable package!
Visit the Official FMS FCX10 Chevy K5 Blazer 1\/10 Scale 4WD Crawler Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.





DIG Transmission System
The FCX10 K5 is equipped with a rear axle DIG, allowing for the rear axle to be locked with simultaneous front-wheel drive. This feature provides the vehicle with a significantly reduced turning radius, allowing for “tank turn” maneuvers.









Magnetic Lighting System
The FCX10 K5 arrives with factory-installed headlights, front turn signals, side turn signals, rear turn signals, reverse lights, and other lighting components. The polycarbonate body uses magnetic connections to the chassis, allowing the lights of the entire vehicle to be activated with a single button on the transmitter.









Counter-Rotating Driveshafts
The drive shafts connecting the front and rear axles rotate in opposite directions to counteract torque twist.









Portal Axles
Heavy-duty portal axles provide additional ground clearance and torque for the most extreme crawling conditions.









Servo On Axle (SOA)
The steering servo is mounted on the front axle, eliminating slop caused by extreme articulation. This enhances precision steering and delivers an improved driving experience.









Mid-Engine Layout Structure
The overall chassis adopts a mid-engine layout structure, optimizing the center of gravity and weight bias for a nimble, precise feel.




Features:

FCX10 scale crawler chassis
Selectable 2WD\/4WD 2-speed transmission
Locking differentials
General Motors Chevrolet licensed K5 body
Durable polycarbonate body
Portal axle
2.4GHz 11-channel radio control system
Chrome-plated body details
Low CG design
Clipless body mounting
Large battery compartment
Oil-filled, coil-over shock absorbers
Metal chassis rails
Metal portal axle gears
Complete ball bearings
Waterproof, metal-geared steering servo
550 brushed motor

Includes:

FMS FCX10 Chevy K5 Blazer Black 1\/10 Scale 4WD Crawler - RTR
2.4GHz transmitter
2-in-1 ESC and receiver (installed)
550 brushed motor (installed)
Lightning system(installed)
Product manual

Requires:

2 cell 7.4V 5000 mAh LiPo battery with XT60 connector - we recommend Admiral 5300mAh 2S 7.4V 60C Hard Case LiPo Battery with XT60 Connector

Four (4) AA size batteries for the radio transmitter we recommend Admiral NiMH AA Rechargeable Batteries (4 Pack)

Minimum 2 cell battery charger - select a minimum 2 cell battery charger from our Battery Collection
