M7 200W 6 Cell (6S) LiPo DC Multifunction Battery Charger from ToolkitRC - TK11400
The ToolkitRC M7 is a feature-rich, high-performance balance charger designed to meet the demands of hobbyists, RC enthusiasts, and professionals. Capable of handling batteries across a variety of chemistry types including LiPo, LiHV, LiFe, LiIon, and NiMH, the M7 delivers an impressive 200W of maximum charging power. Its vibrant 2.0" IPS color display provides easy-to-read information, with customizable voice prompts and a multi-angle viewing design for convenient operation. Beyond just charging, the M7 also functions as a servo tester, watt meter, data logger, and more, consolidating multiple tools into a single compact device to declutter your workspace. Whether you need to charge your RC batteries or power your project, the versatile ToolkitRC M7 has you covered.
Note: We recommend reading this Motion RC knowledge blog article about charger amperage and wattage ratings.
Vibrant Color Display and Graphical UI
The bright, colorful, IPS display gives you all the info you need via an easy-to-use interface.
More Than Just A Charger
Not only will the M7 handle all of your charging needs with ease, it also boasts a whole host of additional features such as servo testing, watt meter functionality, DC power output and more!
Small Size, Big Power
The all new M7 features the same compact size as the M6, but now with a 33.3% increase in power output for a total of 200W.
You’re In Control
The M7 features an ergonomic scroll wheel for convenient and precise control as you navigate through the menus.
Features:
Supports 1-6S LiPo, LiHV, LiFe, LiIon, 1-16S NiMH, and 1-10S Pb
Delivers up to 200W of maximum charging power at 10A
Features a vibrant 2.0" IPS color display
Functions as a servo tester, watt meter, data logger, and more
Compact and portable design to declutter your workspace
Measures PWM, PPM, SBUS, voltage, and internal resistance
Provides 500-2500μs PWM and 880-2200μs PPM\/SBUS output
XT60 output for ease of use with most batteries
Firmware upgradable via USB for future enhancements
Includes:
ToolkitRC M7 200W 6 Cell (6S) LiPo DC Multifunction Battery Charger
USB cable
User Manual
Requires:
External power supply\/power source
** LiPo BATTERY CHARGER SAFETY WARNING **
Never, under ANY circumstances, leave your charger unattended while charging a LiPo battery. Keep the charger away from moisture, dust, direct sunlight, or any heat sources. The charger should always be placed on a heat-resistant, non-flammable surface during charging. Never overcharge or exceed a 1C charge current. A 1C charge current means the charge current equals the capacity of the battery. For example, a 2200mAh battery should never be charged using a current greater than 2.2 Amps (2200mAh).
