M6DAC 700W 6 Cell (6S) Dual Port LiPo AC\/DC Battery Charger from ToolkitRC - TK11500
The ToolkitRC M6DAC is an exceptional dual-channel charger designed with the needs of RC hobbyists in mind. Its advanced capabilities allow up to 700W of power output to quickly charge a wide range of battery types, from 1-6S LiPo, LiHV, LiFe, LiIon, as well as NiMH and Pb configurations. The M6DAC features a versatile dual-mode input, supporting both a built-in 200W AC power supply that eliminates the need for bulky external adapters, as well as a wide DC input range from 7-28V at up to 30A, allowing you to power the charger directly from a high-capacity battery or other DC power supply and expanding your charging options beyond just AC wall outlets. The large, 3.5" IPS display provides easy monitoring of charging status, while the tactile metal dial wheel offers precise control over all charger settings and functions, making the ToolkitRC M6DAC the ultimate dual-channel charger for the modern RC hobbyist.
Note: We recommend reading this Motion RC knowledge blog article about charger amperage and wattage ratings.
Vibrant Color Display and Graphical UI
The bright, colorful, IPS display gives you all the info you need via an easy-to-use interface.
Dual Channel Output
Charge two batteries simultaneously with up to 700W charging power.
AC\/DC Dual Input
With the internal 200W AC power supply and up to 700W DC via the XT90 input plug, you’ll never be short on power options.
USB-C Fast Charging
Support for up to 65W fast charging via USB-C to power all your portable devices.
Features:
Dual-channel charging with advanced asynchronous and synchronous modes for up to 700W of power output
Supports a wide range of battery types including LiPo, LiHV, LiFe, LiIon, NiMH, and Pb
65W USB-C fast charge output for quickly replenishing mobile devices
Large 3.5" IPS display with full viewing angles for easy monitoring of charging parameters
Metal dial wheel provides excellent tactile feedback and precise control over charging settings
Built-in 200W AC power supply eliminates the need for external adapters
Wide 7-28V DC input voltage range allows powering from various sources like power banks and vehicle outlets
XT60 output for ease of use with most batteries
Compact and durable design ideal for use in the field by RC hobbyists
Includes:
ToolkitRC M6DAC 700W 6 Cell (6S) Dual Port LiPo AC\/DC Battery Charger
USB cable
AC Power Cord
User Manual
** LiPo BATTERY CHARGER SAFETY WARNING **
Never, under ANY circumstances, leave your charger unattended while charging a LiPo battery. Keep the charger away from moisture, dust, direct sunlight, or any heat sources. The charger should always be placed on a heat-resistant, non-flammable surface during charging. Never overcharge or exceed a 1C charge current. A 1C charge current means the charge current equals the capacity of the battery. For example, a 2200mAh battery should never be charged using a current greater than 2.2 Amps (2200mAh).
