ER6 6-Channel ELRS PWM Receiver from RadioMaster - HP0157-RX-ER6
The RadioMaster ER series of PWM receivers utilize the innovative ExpressLRS (ELRS) protocol, delivering exceptional performance, reliability, and versatility. With quick response times and an incredibly long range, these receivers bring you the best that ELRS technology has to offer.
The ER6 ELRS receiver is specifically designed for fixed-wing aircraft users. It supports up to 6 servos and includes built-in telemetry for both receiver and flight battery voltage, automatically detecting the appropriate voltage input. For future expansions, a 4-wire CRSF interface is included to easily connect additional telemetry sensors. The ER6 is equipped with a dual-antenna system and offers telemetry power of up to 100mW. Additionally, its casing is made using a one-piece molding process, ensuring high structural integrity and durability.






































































Features:

Built on the revolutionary ExpressLRS protocol
High performance and reliability with flexible configuration, fast response times, and ultra-long range
Supports 6 PWM channels
Optimized PCB design for improved performance
Automatic telemetry for external battery voltage or built-in receiver voltage
Supports Wi-Fi updates and WEBUI configuration
High-quality 2.54 mm connector
Comes with a standard 20cm high-sensitivity dual antenna
Compatible with all 2.4GHz ExpressLRS modules and transmitters equipped with built-in 2.4GHz ExpressLRS

Includes:

RadioMaster ER6 6-Channel ELRS PWM Receiver
Voltage telemetry wire (Type-B)
CRSF wire
ELRS- RX- SBUS wire
User card

Requires:

ELRS compatible transmitter
