180A Watt Meter and Power Analyzer from GT Power - GTP180AWM
\nThe GT Power 180A Power Analyzer with backlit display is a "must have" diagnostic tool for the RC enthusiast. This self-powered device allows you to measure power and energy consumption of any device with a battery. Use it to ensure peak currents are safe for motor, ESC, wiring and connectors. Test motors, propellers, and EDFs to determine their safe operating ranges. You can also check battery health and performance and evaluate charging efficiency. The GT Power 180A Watt Meter and Power Analyzer does it all it in one convenient, portable device. Please note, this meter comes with bare wires so you can solder on the connectors of your choice (see spare parts tab above for a full listing of compatible connectors).
Features:
\nMeasures the circuit safety and 8 main performance parameters
Prevents damage to the battery, motor, ESC, wires and connectors caused by high current
You can check the load voltage, and set up the safety voltage
You can check the capacity and the performance
Keeps each cell's parameter balanced to for normal charger operation
Detects the actual working current of the devices to decide whether a UBEC is needed
The unit can start to measure from 0V if there is an external power supply
\nSpecifications:
\nOperates without auxillary battery from 4.8 to 60V or with an optional auxiliary battery
Measures 0 to 180A, resolution 0.01A
Measures 0 to 60V, resolution 0.01V
Measures 0 to 6554W, resolution 0.1W
Measures 0 to 65 Ah, resolution 0.001 Ah
Measures 0 to 6554 Wh, resolution 0.1 Wh
16 x 2, backlit LCD display
Dimension: 85mm x 42mm x 25mm
Weight: 82g
